HAS VIDEO Straight / Flexible PP PE plastic drinking straw extrusion making machine for juice,coffee stir,milk

FOB Reference Price:Get Latest Price
$9,800.00 - $29,800.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
XIAOHAI
Model Number:
XG
Voltage:
380v 50hz or 220v 50hz
Power(W):
14KW
Dimension(L*W*H):
7.2*1.3*1.5m
Weight:
1000kg
Certification:
CE
Warranty:
One year
After-sales Service Provided:
Engineers available to service machinery overseas
Product::
drinking straw,nozzle, cotton slip,lollipop stick
Straw colors::
one color, two colors,three colors and more
Supply Ability
Supply Ability:
11 Set/Sets per Month
Packaging & Delivery
Packaging Details
wooden case
Port
Ningbo
Lead Time :
20 days
Product Description

















Usage:
1.This automatic PP PE drinking straw making machine is wildly used for producing drink straw,nozzle,cotton bud stick,lollipop stick,tooth pick stick,ball-pen core,watercolor pen core,toy tube,drop tube and other small industrial irregular shape pipes.

2.This drinking straw extruder is with inverter extruding system,mould,vacuum cooling water tank or cooling water tank,take up and cutting device etc.It make different diameter and length straight straws.



Specification:





Model No.

XG-1

XG-2

XG-3

XG-4

One color Straw

Double colors straw

Tricolor Straw

Four Colors Straw

Extruder

Screw dia.

50 or 55

50 or 55

50 or 55

50 or 55

Screw L/D ratio

25:1

25:1

25:1

25:1

Motor

11kw or 15kw

11kw or 15kw+
0.7kwx1

11kw or 15kw+
0.7kwx2

11kw or 15kw+
0.7kwx3

Take up and Cutting Device

Inveter

0.75KW×2

0.75KW×2

0.75KW×2

0.75KW×2

Capability

Extruding Output

25-35Kg

25-35Kg

25-35Kg

25-35Kg

Product length

≥5mm

≥5mm

≥5mm

≥5mm

Product Outer Dia.

0.8mm-8mm or 0.8mm-13mm

0.8mm-8mm or 0.8mm-13mm

0.8mm-8mm
or 0.8mm-13mm

0.8mm-8mm or 0.8mm-13mm

Total Weight

900

1000

1200

1300
