Pp Lid Making Machine Price

FOB Reference Price:Get Latest Price
$9,900.00 - $10,700.00 / Set | 1 Set/Sets (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Processing Type:
Plastic Thermoforming Machine
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
xiaohai
Model Number:
PP LID MAKING MACHINE
Voltage:
380v
Certification:
Other
Product Type:
Plastic Cup
Dimension(L*W*H):
2700*830*1450mm
After-sales Service Provided:
Engineers available to service machinery overseas
Power(W):
5kw
Warranty:
1 year
Weight:
800kg
Supply Ability
Supply Ability:
10 Set/Sets per Month
Packaging & Delivery
Packaging Details
wooden box. PP LID MAKING MACHINE.
Port
NINGBO PORT
Lead Time :
30 days PP LID MAKING MACHINE



PP lid Making Machine

1. Introduction

XHL-001 PP lids forming machine are developed by our research and development personnel according to the demand of packing market. In combination with the advantages of aluminum-plastic blister packing machine and plastic sucking forming machine, this machine is a new type product developed in light of pharmaceutical standard GMP and food standard QS. This machine adopts a fully automatic flow covering blow molding or plastic suction molding, punching and diet cutting as the special properties of products required by the users. It is with advanced technology, safe and simple operation, which will avoid the consumption of labor on the manual punching and contamination from the touch with the employee. Therefore, the quality requirement is secured during the production. Aligned heating is employed by the equipment, and it enjoys low power consumption, small covering of land. It is applicable to the plastic ware such as PP , PVC, PET, PS medicine trays, and cup lids thermoforming boxes.



 PP CUP LID MAKING MACHINE.jpg



2. Performance features

1. Speed reducer, main-rotating connection, main shaft are on line (to decrease driving error) for mechanical transmission.

2.Sensor controls are adopted in pneumatic system .PLC control makes the whole machine run smoothly, keeps synchronous stability during the products are to be packed in multi-labor, long- distance .

3. Main motor non-stop speed regulating, the travel adjustable at will, simple and convenient to change the mold, manipulator traction, stable running.

4. Positive pressure formation in the equipment (Puffing forming)

3. Main technical parameters

Punch Frequency

10-35punch/min

Total Power

9Kw

Material thickness

0.1-0.8mm

Mould cooling

Tap water or recycle water 60 L/H

Max. Forming area

430×240mm

Machine dimension

4000×1200×1700mm

Max. Forming depth

46mm

Weight

2000KG

Stroke

20-260mm

Compressed air

0.5-0.8(mpa)
