coreless thermal paper rolls machine

FOB Reference Price:Get Latest Price
$10,000.00 - $16,000.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Slitting Rewinder, Thermal paper slitting machine
Dimension(L*W*H):
2.5M*2.1M*1.6M
Weight:
3500KG
Condition:
New
Computerized:
Yes
Place of Origin:
Zhejiang, China
Brand Name:
XIAOHAI
Model Number:
PPD-700/900 thermal paper slitting machine
Voltage:
380V,50/60HZ
Power(W):
4.5KW
Certification:
CE
Reel paper core inner Diameter:
76mm
Max width of paper:
700MM
Max Diameter of unwinding:
750MM
Max.rewind Diameter:
160MM
Cutting speed:
168M/min
Power Voltage:
380V, 50/60HZ
Uploading Device:
Hydraulic
Control:
PLC control
Tension control:
Automatic
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
ONE YEAR
Supply Ability
Supply Ability:
35 Set/Sets per Month
Packaging & Delivery
Packaging Details
Exported seaworthy packing for thermal slitting machine.
Port
NINGBO

coreless Thermal Paper roll Cash roll Till roll making machine

Product Description



1. Features:

The Automatic thermal paper slitting machine mainly is suitable for slitting all kinds of FAX PAPER,

CASH REGISTER, COMPUTER BILL, MEDICAL RECORD PAPER,POS PRINTING PAPER,

ATM REEL PAPER, film and self adhesive paper etc.

It is the most advanced numerical control cash register slitting equipment in China.

2.Advantages:

1)surface rewinding way, automatic replicate, insert reel

2)Controls bag length through the human-machine interface.
3)Touch Screen (PLC ) for calculating parameters.
4)Unwinding is used to automatic loading system

5) tension force is controlled by the Magnetic Brake

6)Automatic Lift System

3.Technical Parameters:

Max width700mm/900MM
Max unwinding diameter1000mm
Reel paper core inner diameter76mm(3")
Standard Slitting width28,30,57,65,75,80...
Max rewinding diameter160mm
Slitting Speed168m/min
total power4.5kw
Power supply380,50hz/220,50HZ
Machine Size2.5*2.1*2.1m



Packaging & Shipping
